Jalur tes motor

Model

500 jinis (kabeh model)

250 jinis (rodha loro)

Aplikasi

Beban roda (kg)

≤500

≤250

Jembar Tirus (MM)

40-250

40-250

Dasar Roda (MM)

900-2,000

900-1,00

Reresik lemah

≥65

≥65

Rear wheel inner width of a regular three-wheeled motorcycle

≥800

Wheel Roda njaba sisih njaba motor roda sing biasa

≤1,600

Tes Motosikal Roda

Ukuran piring sing bobote (L x w)

1,600x430

350x180

Max. Bobot (kg)

500

250

Resolusi (kg)

1

Kesalahan indikasi

± 2%

Ukuran Sakabèhé (LXWXH) mm

1,690x520x178

400x520x158

Tes brek motor

DITANGGIHAN (KG)

500

250

Power Motor (KW)

2x0.75kw

0,75kw

Ukuran roller (mm)

Φ195x1,000 (roller dawa)

Φ195x300 (cendhak roller)

Φ195x300

Jarak Roller Center (MM)

310

310

MeaSurable Max. Angkatan Braking (N)

3,000

1.500

Kesalahan Indikasi Angkatan Braking

<± 3%

Pasokan Daya Motor

AC380 ± 10%

Meksa kerja (MPA)

0,6-0.8

Ukuran Sakabèhé (LXWXH) mm

2710x740x250

1,150x740x250

Tes kacepetan motor

DITANGGIHAN (KG)

500

250

Power Motor (KW)

3

3

Ukuran roller (mm)

Φ190x1,000 (dawa roller)

Φ190x300 (cendhak roller)

Φ190x300

Jarak Roller Center (MM)

310

310

MeaSurable Max. Kacepetan (km / h)

60

Resolusi (km / h)

0.1

Pasokan Daya Motor

AC380 ± 10%

Meksa kerja (MPA)

0,6-0.8

Ukuran Sakabèhé (LXWXH) mm

2,290x7404050

1,150x740x250

Alignment Roda Pit motor

Jarak pusat ing ngarep lan mburi (MM)

1,447

Clamp efektif stroke (mm)

40-250

Pangukuran maksimal (MM)

± 10

Kesalahan Indikasi (MM)

± 0.2

Meksa kerja (MPA)

0,6-0.8

Ukuran Sakabèhé (LXWXH) mm

2,580890x2850

Clamp Motosikal

Lenga sing efektif clamp (mm)

1,340

Clamp efektif stroke (mm)

40-300

Meksa sumber (MPA)

0,6-0.8

Ukuran Sakabèhé (LXWXH) mm

1,400x890x250
